Enjoy large images from short distances with the Epson PowerLite 685W 3500-Lumen WXGA Ultra-Short-Throw 3LCD Projector. Its ultra-short 0.28 to 0.37:1 throw ratio can produce up to a 100" image from under 2' away, virtually eliminating shadows caused by presenters or passers-by. Its 3500 lumens of brightness, combined with its 14,000:1 dynamic contrast ratio, helps it overcome ambient light in many situations and retain detail in dark areas of the image without compromising overall brightness. The 1280 x 800 native resolution helps ensure that images and text are clear at most viewing distances.
The PowerLite 685W features RCA, two VGA, and three HDMI inputs to support a variety of source devices. One HDMI input is MHL-compatible for projecting from your compatible mobile device, and one VGA input can instead act as an output to daisy-chain multiple projectors or displays. An IR remote is included as an added convenience.
Designed to Produce Bright, Colorful Images
Ultra-Short Throw Distance
HDMI Connectivity with MHL
iProjection Compatible
Designed for Long Lamp Life
Additional Features
- Compatible with the M685 and 885 SMART Board interactive whiteboards, including control via the SMART Extended Control Panel (ECP)
- Manage your display and send announcements remotely with network connectivity and included software
- RoHS-compliant, recyclable design
Epson 685W Specs
| Display System | 3-Chip LCD |
| Native Chip Resolution | 1280 x 800 (WXGA) |
| Supported Resolutions | Maximum: UXGA - 1600 x 1200 |
| Max Brightness | White: 3500 Lumens Color: 3500 Lumens |
| Aspect Ratio | Native: 16:10 |
| Dynamic Contrast Ratio | 14,000:1 |
| Color Depth | 10-Bit (1.07 Billion Colors) |
| Focus | Manual |
| Lens | f/1.6 (f = 3.7 mm) |
| Optical Zoom | None |
| Throw Distance | 13.386 - 23.622" / 0.34 - 0.6 m |
| Throw Ratio | 0.28 to 0.37:1 |
| Projection Size | 60 - 100" / 152.40 - 254.00 cm |
| Keystone Correction | Manual-Vertical: ± 3° Manual-Horizontal: ± 3° |
| Digital Zoom | 1.35x |
| Ceiling Mountable | Yes |
| Rear Screen Projection | Yes |
| Built-In Speaker | Yes (Mono) |
| Speaker Power | 16W |
| Inputs/Outputs | 2 x HDMI Audio/Video (Input) 1 x HDMI with MHL Support Audio/Video (Input) 1 x VGA (DE-15) Video (Input) 1 x VGA (DE-15) Video (Input/Output) 1 x Composite (RCA) Video (Input) 3 x 1/8" / 3.5 mm Mini Audio (Input) 1 x 1/8" / 3.5 mm Mini Microphone (Input) 1 x 1/8" / 3.5 mm Mini Audio (Output) 1 x Ethernet (RJ45) LAN (Input) 1 x USB Type-A Female (Input/Output) 1 x USB Type-B Female (Input) 1 x RS-232C (Unspecified Connector) Control (Input) |
| Wireless LAN / Wi-Fi | No, Optional Adapter Available |
| Light Source | Lamp (1 x UHE) |
| Lamp Power | 250 W |
| Expected Lamp Life | Full Brightness: 5000 Hours Low Brightness: 10,000 Hours |
| Fan Noise | Full Brightness: 35 dB Low Brightness: 29 dB |
| Security | Cable Lock Slot Padlock Password Protection |
| AC Input Power | 100 to 240 VAC, 50 / 60 Hz |
| Power Consumption | Full Brightness: 373 W Low Brightness: 324 W Standby Mode (Lamp Off): <2.2 W |
| Max Operating Altitude | 9843' / 3000 m |
| Operating Temperature | 41 to 104°F / 5 to 40°C |
| Storage Temperature | 14 to 140°F / -10 to 60°C |
| Operating Humidity | 20 - 80% |
| Storage Humidity | 10 - 90% |
| Dimensions (W x H x D) | 14.5 x 7.4 x 15.8" / 36.8 x 18.8 x 40.1 cm Including feet 14.5 x 5.9 x 15.8" / 36.8 x 15.0 x 40.1 cm Excluding feet |
| Weight | 12.6 lb / 5.7 kg |
| Package Weight | 19 lb |
| Box Dimensions (LxWxH) | 21 x 19 x 10" |
